Regulatory

Regulatory Signs
(Stop & Yield)
R1-1 R1-1
18-inch  24-inch
30-inch   36-inch		 Right (or Left) Lane Keep Moving
R1-1A
12 x 18   18 x 24
24 x 30   30 x 36
 R1-2 R1-2
24-inch   30-inch
 TO ONCOMING TRAFFIC
R1-2a
18 x 12   24 x 18
30 x 24   36 x 30		 WAY 2-, 3- or 4-WAY
2-WAY   12 x 6
3-WAY   12 x 6
4-WAY   12 x 6


R1-3P  R1-3P
18 x 6   30 x 12		 Uncontrolled Crosswalk - YIELD
R1-5
18-inch 24-inch
30-inch 36-inch		 Uncontrolled Crosswalk - YIELD
R1-5a
18 x 24  24 x 30  36 x 48		 Stop Here for Pedestrians symbol
R1-5b
18-inch   24-inch
30-inch   36-inch		 Uncontrolled Crosswalk - STOP
R1-5c
18 x 24   24 x 30   36 x 48
Uncontrolled Crosswalk - YIELDFluorescent Yellow-Green R1-6
(Pedestrian Crossing)
R1-6
12 x 36		 Uncontrolled Crosswalk - STOP  Fluorescent Yellow-Green R1-6a
(Pedestrian Crossing)
R1-6a
12 x 36		 Uncontrolled Crosswalk - YIELD (FYG)   Uncontrolled Intersection - STOP (FYG)
R1-6       R1-6a
(Pedestrian Crossing)
(vinyl rollups)
12 x 36     12 x 36    		In-Street School Crossing -YIELD        In-Street School Crossing - STOP
(School Crossing)
 R1-6b            R1-6c
12 x 36           12 x 36

Except Right Turn
R1-10p
18 x 12   24 x 18
30 x 24   36 x 30
Overhead Pedestrian Crossing (YIELD)
R1-9
48 x 18   90 x 24
Overhead Pedestrian Crossing (STOP)
R1-9a
48 x 18   90 x 24

Regulatory Signs
(Movement & Direction)
SPEED LIMIT
R2-1  (Any Speed)
12 x 18   18 x 24
24 x 30   30 x 36		 M P H Plate Black/Yellow
Black/Yellow
W13-1
18-inch  24-inch  30-inch		 M P H Plate - Black/White
Black/White
R2-I101
18-inch    24-inch   30-inch		 Truck Speed Limit
R2-2  (Any Speed)
18-inch   24-inch
30-inch   36-inch		 Night Speed Limit
R2-3  (Any Speed)
18-inch   24-inch
30-inch   36-inch
MINIMUM SPEED
R2-4
(Choose Any Speed)
12 x 18   18 x 24
24 x 30   30 x 36		 Speed Limit and Minimum Speed
R2-4a
(Choose Any Speeds)
24 x 48		 UNLESS OTHERWISE POSTED
R2-5P
18 x 12   24 x 18
30 x 24   36 x 30
 FINES HIGHER
R2-6P
24 x 18   36 x 24		 Citywide Plate
R2-5aP
18×6  24×6
Neighborhood
R2-5bP
18×6  24×6
Residential
R2-5cP
 18×6   24×6
FINES DOUBLE
R2-6aP
24 x 18   36 x 24
 $150 FINE
R2-6bP
24 x 18   36 x 24 		 Begin Higher Fines Zone
R2-10
12 x 18   18 x 24
24 x 30   30 x 36		 End Higher Fines Zone
R2-11
12 x 18   18 x 24
24 x 30   30 x 36
Cell Phone Use Prohibited
R2-I110
18 x 12   24 x 18
30 x 24   36 x 30
No Right Turn symbol
R3-1
18-inch   24-inch
30-inch   36-inch		 No Left Turn symbol
R3-2
18-inch   24-inch
30-inch   36-inch
 NO TURNS
R3-3
18-inch   24-inch
30-inch   36-inch		 No U-Turn symbol
R3-4
18-inch   24-inch
30-inch   36-inch		 U-Turn OK
R3-5-1
18-inch   24-inch
30-inch   36-inch
Mandatory Movement (Left)
R3-5
(Right or Left)
12 x 18   18 x 24
24 x 30   30 x 36		 Mandatory Movement (Forward)
R3-5a
12 x 18 18 x 24

24 x 30 30 x 36




 Optional Movement Lane Control
R3-6
(Right or Left)
12 x 18 18 x 24

24 x 30 30 x 36

 RIGHT LANE MUST TURN RIGHT
R3-7
(Right or Left)
18-inch   24-inch
30-inch   36-inch
R3-8 - Advanced Intersection Lane Control
R3-8
18-inch   24-inch
30-inch   36-inch
Three Lanes - Mandatory Movement
R3-8a
48 x 30
 Three Lanes - Mandatory Movement
R3-8b
48 x 30		 CENTER LANE LEFT TURN ONLY
R3-9
12 x 18   18 x 24
24 x 30   30 x 36		 Two-Way Left Turn Only
R3-9a
12 x 18 18 x 24

24 x 30 30 x 36
CENTER LANE Left Turn ONLY
R3-9b
12 x 24   18 x 30   24 x 36

Begin Plate
R3-9cP
24 x 12-inch
30 x 12-inch
End Plate
R3-9dP
24 x 12-inch
30 x 12-inch		 Bike Lane
R3-17
30 x 24		 AHEAD
R3-17a
30 x 12-inch		 ENDS
R3-17b
30 x 12-inch
No U-Turn or Left Turn symbol
R3-18
18-inch   24-inch
30-inch   36-inch
 Begin Left Turn Lane with Arrow
R3-20L
12 x 24   18 x 30   24 x 36		 Begin Right Turn Lane with Arrow
R3-20R
12 x 24   18 x 30  24 x 36		 No Straight Through Movement

R3-27

18-inch   24-inch
 30-inch   36-inch

 Right Lane Must Exit
R3-33
24 x 12  30 x 1836 x 24
DO NOT PASS
R4-1
12 x 18   18 x 24
24 x 30   30 x 36

PASS WITH CARE
R4-2
12 x 18   18 x 24
24 x 30   30 x 36		 SLOWER TRAFFIC KEEP RIGHT
R4-3
12 x 18   18 x 24
24 x 30   30 x 36		 Begin Right Turn Lane Yield To Bikes

R4-4

36 x 30

 Trucks Use Right Lane
R4-5
12 x 18   18 x 24
24 x 30   30 x 36
Keep Right symbol
R4-7
12 x 18   18 x 24
24 x 30   30 x 36		 KEEP RIGHT arrow right
R4-7a
12 x 18   18 x 24
24 x 30   30 x 36		 KEEP RIGHT oblique arrow
R4-7b
12 x 18   18 x 24
24 x 30   30 x 36		 Keep Left symbol
R4-8
12 x 18   18 x 24
24 x 30   30 x 36		 Keep Left - Arrow West
R4-8a
12 x 18   18 x 24
24 x 30   30 x 36
KEEP LEFT - Arrow Northwest
R4-8b
12 x 18   18 x 24
24 x 30   30 x 36		 Keep Left symbol - Narrow
R4-8c
12 x 24   18 x 30
24 x 36		 Stay in Lane
R4-9
12 x 18   18 x 24
24 x 30   30 x 36		 Form Single Lane
R4-10-1
12 x 18   18 x 24
24 x 30   30 x 36		 Bike - MAY USE FULL LANE
R4-11
18-inch    24-inch
 30-inch    36-inch

Enter Here
R4-14
12 x 18   18 x 24
24 x 30   30 x 36		 Keep Right Except To Pass
R4-16
12 x 18   18 x 24
24 x 30   30 x 36		 Do Not Pass On Shoulder
R4-17
12 x 18   18 x 24
24 x 30   30 x 36		 Do Not Pass On Shoulder
R4-18
12 x 18   18 x 24
24 x 30   30 x 36
 Thru Traffic Stay (Left or Right)
R4-20
18-inch    24-inch
 30-inch    36-inch

Through Traffic Keep Right
R4-H11
12 x 18   18 x 24
24 x 30   30 x 36
  Through Traffic Keep Left
R4-H12
12 x 18   18 x 24
 24 x 30   30 x 36
DO NOT ENTER
R5-1
18-inch    24-inch
30-inch    36-inch

R5-1a R5-1a
30 x 18

36 x 24

42 x 30

No Trucks symbol

R5-2
18-inch   24-inch
30-inch   36-inch
NO TRUCKS

R5-2a



18-inch
   24-inch
30-inch   36-inch
 Except Local Deliveries

R5-2-3

18 x 12   24 x 18

30 x 24   36 x 30

 NO MOTOR VEHICLES
R5-3
18-inch   24-inch
30-inch   36-inch		 No Trucks or Buses
R5-3-4
18 x 12   24 x 18
30 x 24   36 x 30		 Emergency and Authorized Vehicles Only
R5-3-6
12 x 18   18 x 24
24 x 30   30 x 36
No Commercial Vehicles
R5-4
12 x 18   18 x 24
24 x 30   30 x 36
 VEHICLES WITH LUGS PROHIBITED
R5-5
12 x 18   18 x 24
24 x 30   30 x 36		 No Bicycles symbol
R5-6
18-inch   24-inch
30-inch   36-inch		 No Non-Motorized Traffic
R5-7
18 x 12   24 x 18
30 x 24   42 x 24

No Motor-Driven Cycles
R5-8
18 x 12   24 x 18
30 x 24   42 x 24
No Pedestrians Bicycles Motor-Driven Cycles
R5-10a
12 x 18   18 x 24
24 x 30   30 x 36		 No Pedestrians or Bicycles
R5-10b
24 x 12   30 x 18
 NO PEDESTRIANS
R5-10c
24 x 12   30 x 18
 AUTHORIZED VEHICLES ONLY
R5-11
18 x 12   24 x 18
30 x 24   42 x 24		 Begin Class III Truck Route
R5-I101
12 x 18   18 x 24
24 x 30   30 x 36
Class III Truck Route
R5-I102
18-inch   24-inch
 30-inch   36-inch
 Excessive Engine Braking Noise Prohibited
R5-I106
12 x 18   18 x 24
24 x 30   30 x 36
 ONE WAY
R6-1
(Left or Right)
36 x 12    54 x 18
 ONE WAY
R6-2
(Left or Right)
12 x 18   18 x 24
24 x 30   30 x 36

Divided Highway with Straight Lane Extended
R6-3
18 x 12   24 x 18
30 x 24   42 x 24
Divided Highway with Straight Lane Ended
R6-3a
18 x 12   24 x 18
30 x 24   42 x 24


 Roundabout Directional Chevron (2 Stripes)
R6-4
18 x 12  24 x 18  30 x 24		 Roundabout Direction Chevron (3 Stripes)
R6-4a
24 x 12  36 x 18  48 x 24		 Roundabout Directional Chevron (4 Stripes)
R6-4b
30 x 12    60 x 24		 Roundabout Circulation sign
R6-5P
18-inch   24-inch   30-inch

BEGIN ONE WAY
R6-6
12 x 18   18 x 24
24 x 30   30 x 36
 END ONE WAY
R6-7
12 x 18   18 x 24
24 x 30   30 x 36
 		ENTER ONLY
R6-10
12 x 18   18 x 24
24 x 30   30 x 36
 ENTER arrow right
R6-10a
(Left or Right)
12 x 18   18 x 24
24 x 30   30 x 36
 EXIT ONLY
R6-11
12 x 18   18 x 24
24 x 30   30 x 36
EXIT arrow left
R6-11a
(Left or Right)
12 x 18   18 x 24
24 x 30   30 x 36		 Emergency Parking Only
R8-4
18 x 12   24 x 18
30 x 24   36 x 30		 No Stopping On Pavement
R8-5
12 x 18   18 x 24
24 x 30   30 x 36		 No Stopping On Pavement
R8-6
12 x 18   18 x 24
24 x 30   30 x 36		 Emergency Stopping Only
R8-7
18 x 12   24 x 18
30 x 24   36 x 30
Unattended Vehicles Subject to Towing
R8-VP1
24 x 12   36 x 18  48 x 24		 Walk On Left Facing Traffic
R9-1
12 x 18   18 x 24
24 x 30   30 x 36		 Cross Only At Crosswalks
R9-2
12 x 18   18 x 24
24 x 30   30 x 36		 No Pedestrian symbol
R9-3
18-inch   24-inch
30-inch   36-inch		 NO PEDESTRIAN CROSSING
R9-3a
12 x 18   18 x 24
24 x 30   30 x 36
Use Crosswalk (Arrow)
R9-3bp
18 x 12		 No Hitch-Hiking symbol
R9-4
18-inch   24-inch
30-inch   36-inch		 NO HITCH HIKING
R9-4a
12 x 18   18 x 24
24 x 30   30 x 36
 SIDEWALK CLOSED
R9-9
24 x 12   30 x 18
48 x 24
 SIDEWALK CLOSED USE OTHER SIDE
R9-10
24 x 12   30 x 18   48 x 24
Sidewalk Closed Ahead with Arrow (Right or Left) Cross Here
R9-11
18 x 12   24 x 18
30 x 24   36 x 30		 Sidewalk Closed (Arrow Right or Left) Cross Here
R9-11a
24 x 12   30 x 18   48 x 24
 No Skating symbol
R9-13
18-inch   24-inch
30-inch   36-inch		 No Horse Riding symbol
R9-14
18-inch   24-inch
30-inch   36-inch		 No Fishing from Bridge
R9-V1
12 x 18   18 x 24
24 x 30   30 x 36
Cross Only On Green with Green Ball
R10-1
12 x 18  18 x 24
24 x 30  30 x 36		 Cross Only on Signal
R10-2
9 x 12		 Push Button For (Crosswalk Signal)
R10-3
9 x 12		 Push Button to Cross Street Wait for (Walk Signal)
R10-3a
9 x 15		 Educational Crosswalk Sign
R10-3b
9 x 12
Educational Crosswalk Sign
R10-3c
9 x 12		 Educational Crosswalk Sign
R10-3d
9 x 12		 Educational Crosswalk Sign with Arrow - 9x15-inch
R10-3e
9 x 15		 Push Button for Green
R10-4
9 x 12
 Push Button to Cross Street Wait for Green
R10-4a
9 x 15
LEFT ON GREEN ARROW ONLY
R10-5
12 x 18   18 x 24
24 x 30   30 x 36
 STOP HERE ON RED
R10-6
(Right or Left)
 18 x 30   24 x 36		 STOP HERE ON RED
R10-6a
12 x 18   18 x 24
24 x 30   30 x 36		 DO NOT BLOCK INTERSECTION
R10-7
12 x 18   18 x 24
24 x 30   30 x 36		 Do Not Block Crosswalk
R10-7a
18-inch   24-inch
30-inch   36-inch
USE LANE WITH GREEN ARROW
R10-8
12 x 18   18 x 24
24 x 30   30 x 36		 Right Turn On Red After StopR10-9
12 x 18   18 x 24
24 x 30   30 x 36		 No Right Turn On Red
R10-9a
12 x 18   18 x 24
24 x 30   30 x 36		 No Right Turn ON RED
R10-9b
12 x 18   18 x 24
24 x 30   30 x 36		 No Left Turn ON RED
R10-9c
12 x 18   18 x 24
24 x 30   30 x 36
Left (or Right) Turn Signal
R10-10
(Left or Right)
12 x 18   18 x 24
24 x 30   30 x 36		 R10-11
R10-11
12 x 18   18 x 24
24 x 30   30 x 36		 NO TURN ON RED (Rectangle)
R10-11a
12 x 18   18 x 24
24 x 30   30 x 36		 NO TURN ON RED (Square)
R10-11b
18-inch   24-inch
30-inch   36-inch		 No Turn On Red Except From Right Lane
R10-11c
18 x 30   24 x 36 30 x 42
No Turn On Red From This Lane
R10-11d
18 x 30 24 x 36 30 x 42
LEFT TURN YIELD ON GREEN
R10-12
12 x 18   18 x 24
24 x 30   30 x 36

EMERGENCY SIGNAL

R10-13

30 x 18  36 x 24
42 x 30
 Emergency Signal Stop On Flashing Red
R10-14
36 x 42		 Turning Vehicles Yield to Pedestrians
R10-15
(Right or Left)
18-inch   24-inch
30-inch   36-inch
U-Turn Yield to Right Turn
R10-16
12 x 18   18 x 24
24 x 30   30 x 36		 Turn on Flashing Red with Caution After Stop
R10-17
18-inch   24-inch
30-inch   36-inch		 Right on Red Arrow After Stop
R10-17a
12 x 18   18 x 24
24 x 30   30 x 36		 TRAFFIC LAWS PHOTO ENFORCED
R10-18
30×18  36×24 42×30

Traffic Laws Photo Enforced
R10-18PA
24×12  36x 8  48×30
Photo Enforcement symbol
R10-19P
24 x 12  36 x 18  48 x 24		 PHOTO ENFORCED
R10-19aP
18 x 12   24 x 18
30 x 24   36 x 30
PHOTO ENFORCED
SR56-California
18 x 30   24 x 36  30 x 42

Crosswalk STOP On Red
R10-23
12 x 18   18 x 24
24 x 30   30 x 36


Push Button to Turn on Warning Lights
R10-25
9 x 12
Left Turn Yield on Flashing Red Arrow After Stop
R10-27
12 x 18   18 x 24
24 x 30   30 x 36
 One Vehicle Per Green
R10-28
12 x 18   18 x 24
24 x 30   30 x 36		 1 Vehicle Per Green Each Lane
R10-29
24 x 12   30 x 18
 36 x 24		 Right Turn on Red Must Yield to U Turn
R10-30
12 x 18   18 x 24
24 x 30   30 x 36		  At Signal R10-31p
24 x 9
Push Button for 2 Seconds for Extra Crossing Time
R10-32p
9 x 12
KEEP OFF MEDIAN
R11-1
12 x 18   18 x 24
24 x 30   30 x 36		 WEIGHT LIMIT
R12-1
(Any Weight)
12 x 18   18 x 24
24 x 30   30 x 36
Axle Weight Limit
R12-2
(Any Weight)
12 x 18  18 x 24
24 x 30   30 x 36		 No Trucks Over Certain Empty Weight
R12-3
(Any Weight)
12 x 24 18 x 30 24 x 36
Weight Limit Per Axle
R12-4
(Any Weight)
24 x 12 30 x 18 36 x 24		 Weight Limit
R12-5
(Any Weights)
12 x 24   18 x 30   24 x 36		 Bridge Weight Limit (Virginia)
R12-V1
(Any Weights)
12 x 18  18 x 24
24 x 30   30 x 36		 Bridge (Virginia)
R12-VP1
24 x 12    30 x 15   36 x 18
 Trucks Over 10 Tons Must Enter Weigh Station Next Right
R13-1
60 x 30     72 x 54
96 x 72   120 x 90
(Call to order)
All Trucks Must Enter Rest Area
R13-2
18-inch   24-inch
30-inch   36-inch		 TRUCK ROUTE
R14-1
18 x 12   24 x 18   30 x 24
 Hazardous Material Route
R14-2
18-inch   24-inch
30-inch   36-inch		 Hazardous Materials Prohibited
R14-3
18-inch   24-inch
30-inch    36-inch		 National Network (Trucks) Permitted
R14-4
18-inch   24-inch
30-inch    36-inch

National Network (Trucks) Permitted
R14-5
18-inch    24-inch
30-inch    36-inch		 Brake Retarders Prohibited Within City Limits
R14-9
12 x 18   18 x 24
24 x 30   30 x 36		 End Brake Retarder Prohibition
R14-9A
18 x 12   24 x 18
30 x 24   36 x 30
Trucks Reduce Gear
R14-10
18 x 12   24 x 18
30 x 24   36 x 30		 Fender Bender Move Vehicles From Travel Lanes
R16-4
24 x 12 30 x 18
36 x 24
Lights On When Using Wipers
R16-5
12 x 18   18 x 24
24 x 30   30 x 36
Lights On When Raining
R16-6
12 x 18   18 x 24
24 x 30   30 x 36
Turn On Headlights Next XXX Miles
R16-7
48 x 15

Turn On Headlights
R16-8
24 x 12   30 x 18  48 x 24
Check Headlights
R16-9
24 x 12   30 x 18
48 x 24

r16-10

R16-10
48 x 15

 r16-11R16-11
48 x 15

fr5-11a

FR5-11a
18×12 24×18 30×24

FR5-11b

FR5-11b
12×18 18×24 24×30

 FR11-4a

FR11-4a
48×24  60 x 30

FR11-4b

FR11-4a
48×24  60×30

FR11-4c

FR11-4c
36×18   48×24   60×30

 R5-1m
12×18  18×24  24×30		 R3-5b
12×18  18×24 24×30

Regulatory Signs – Canada
Canadian Advance Speed Limit Warning
CAN-R-3  (Any Speed)
12 x 18   18 x 24
 24 x 30   30 x 36		 Canadian Speed Limit
CAN-R-4  (Any Speed)
12 x 18   18 x 24
24 x 30   30 x 36		 Canadian Speed Limit Ends
CAN-R-5(Any Speed)
12 x 1818 x 24
24 x 3030 x 36		 Canadian Time Plate for OK Movement symbols
CAN-R-15T
24×12-inch
30×18-inch		 Canadian OK to Turn symbol
CAN-R-16
18-inch   24-inch 30-inch 36-inch
Canadian OK Straight Ahead symbol
CAN-R-17
18-inch   24-inch
30-inch   36-inch

 Canadian OK to Turn Right or Left symbol
CAN-R-18
18-inch   24-inch
30-inch   36-inch		 Canadian No Passing
CAN-R-22
18-inch   24-inch
30-inch   36-inch		 Canadian OK to Pass
CAN-R-23
18-inch  24-inch
30-inch    36-inch
